Fuse Holders

Class H, R and J fuse holders with box distribution connectors.

Styles:
- Barrier

Amp / Volt Range:
- 30-60 A
- 250-600 V

Withstand / SCCR:
- See Datasheets

For branch and small motor protection where high current limitation is required.

Styles:
- Barrier
- Enclosed

Amp / Volt Range:
- 30-60 A
- 600 V

Withstand / SCCR:
- 200,000

For CC fusing; the Fused Disconnect Switch incorporates the switch functionality of a circuit breaker with the high protection level of a fuse.

Styles:
- Enclosed

Amp / Volt Range:
- 30 A
- 600 V

Withstand / SCCR:
- 200,000

For use in branch circuits where higher performance and lower power levels are needed.

Styles:
- Barrier, Open

Amp / Volt Range:
- 15-30 A
- 480-600 V

Withstand / SCCR:
- 100,000

Recognized fuse holders for semi-conductor, L Class or others with variable geometry and include bolt down mounting profiles.

Styles:
- Stud, Stud / Terminal

Amp / Volt Range:
- 100-1200 A
- 1000 V

Withstand / SCCR:
- See Datasheets

For protection where frequent outages are common and low levels of available fault current are available.

Styles:
- Barrier
- Panel-Board

Amp / Volt Range:
- 30-600 A
- 250-600 V

Withstand / SCCR:
- 10,000

For maximum protection of motors, controllers or panels.

Styles:
- Barrier, Open
- Enclosed

Amp / Volt Range:
- 30-600 A
- 250-600 V

Withstand / SCCR:
- 200,000

Supplemental fuses similar to the size of a CC, used in more general applications where current limitation requirements are lower.

Styles:
- Barrier
- Enclosed
- Sectional

Amp / Volt Range:
- 30-60 A
- 600 V

Withstand / SCCR:
- See Datasheets

Designed for bus bar termination. Uniquely designed with terminals to accept standard stock bus bar eliminating the need for custom fabricated bus bar.

Styles:
- Enclosed

Amp / Volt Range:
- Up to 30A
- 1000 V

Withstand / SCCR:
- 30,000

For higher levels of protection at the same size of the H Class, where higher levels of fault current potential exists.

Styles:
- Barrier

Amp / Volt Range:
- 30-600 A
- 250-600 V

Withstand / SCCR:
- 200,000

For a high degree of protection and half to a third the size of R Class fuses.

Styles:
- Barrier, Open

Amp / Volt Range:
- 30-600 A
- 300-600 V

Withstand / SCCR:
- 200,000
