Power Distribution Block Selector Tool

FILTERS

Style

Poles

Amps

Select minimum amps

Volts

Select minimum volts

Line Side Connector Openings/Poles

Line Side Wire Range

Load Side Connector Openings/Poles

Load Side Wire Range

Connector Material

Insulator Material

Agency

Clear Filters

Amps LINE SIDE LOAD SIDE Feeder Circuit Compliant per UL 508 Catalog #
Wire Range
AWG / kcmil		 Connector
Openings / Pole		 Wire Range
AWG / kcmil		 Connector
Openings / Pole
115 #2 - #14 1 #2 - #14 1 -- 1411300
Product image for 1411300
  • Catalog #: 1411300
  • Available Cover Part #: CC1411
  • Style: Open
  • Poles: 1
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: #2 - #12
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: #2 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    0.85" x 2.29" x 1.62"
  • Weight: 0.09 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 #2 - #14 1 -- 1412300
Product image for 1412300
  • Catalog #: 1412300
  • Available Cover Part #: CC1412
  • Style: Open
  • Poles: 2
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: #2 - #12
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: #2 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.48" x 2.29" x 1.62"
  • Weight: 0.15 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 #2 - #14 1 -- 1413300
Product image for 1413300
  • Catalog #: 1413300
  • Available Cover Part #: CC1413
  • Style: Open
  • Poles: 3
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: #2 - #12
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: #2 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.12" x 2.29" x 1.62"
  • Weight: 0.23 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 #2 - #14 1 -- 1414300
Product image for 1414300
  • Catalog #: 1414300
  • Available Cover Part #: CC1414
  • Style: Open
  • Poles: 4
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: #2 - #12
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: #2 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.75" x 2.29" x 1.62"
  • Weight: 0.28 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 (1) Female 1/4' KT for #10 & #2 - #14 1 -- 1414301
Product image for 1414301
  • Catalog #: 1414301
  • Available Cover Part #: CH1414
  • Style: Open
  • Poles: 4
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: (1) Female 1/4' KT for #10 & #2 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.75" x 2.29" x 1.62"
  • Weight: 0 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 (2) Female 1/4' KT for #10 2 -- 1414205
Product image for 1414205
  • Catalog #: 1414205
  • Available Cover Part #: CH1414
  • Style: Open
  • Poles: 4
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: (2) Female 1/4' KT for #10
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.75" x 2.29" x 1.62"
  • Weight: 0 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 #10 - #18 4 -- 1413400
Product image for 1413400
  • Catalog #: 1413400
  • Available Cover Part #: CC1413
  • Style: Open
  • Poles: 3
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: #10 - #18
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.12" x 2.29" x 1.62"
  • Weight: 0.23 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 #10 - #18 4 -- 1414400
Product image for 1414400
  • Catalog #: 1414400
  • Available Cover Part #: CC1414
  • Style: Open
  • Poles: 4
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: #10 - #18
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.75" x 2.29" x 1.62"
  • Weight: 0.31 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 #10 - #18 4 -- 1412400
Product image for 1412400
  • Catalog #: 1412400
  • Available Cover Part #: CC1412
  • Style: Open
  • Poles: 2
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: #10 - #18
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.48" x 2.29" x 1.62"
  • Weight: 0.15 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 #10 - #18 4 -- 1411400
Product image for 1411400
  • Catalog #: 1411400
  • Available Cover Part #: CC1411
  • Style: Open
  • Poles: 1
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: #10 - #18
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    0.85" x 2.29" x 1.62"
  • Weight: 0.09 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 2/0 - #14 1 Yes 1321572
Product image for 1321572
  • Catalog #: 1321572
  • Available Cover Part #: CH1321
  • Style: Open
  • Poles: 1 - Snap-on
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: 2/0 - #6
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: 2/0 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1" x 3" x 2.42"
  • Weight: 0.15 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 2/0 - #14 1 Yes 1321972
Product image for 1321972
  • Catalog #: 1321972
  • Available Cover Part #: CH1321
  • Style: Open
  • Poles: 1 - Snap-on
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: 2/0 - #6
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: 2/0 - #14
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1" x 3" x 2.42"
  • Weight: 0 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 2/0 - #14 1 Yes 1322572
Product image for 1322572
  • Catalog #: 1322572
  • Available Cover Part #: CH1322
  • Style: Open
  • Poles: 2
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: 2/0 - #6
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: 2/0 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.82" x 3" x 2.42"
  • Weight: 0.28 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 2/0 - #14 1 Yes 1322972
Product image for 1322972
  • Catalog #: 1322972
  • Available Cover Part #: CH1322
  • Style: Open
  • Poles: 2
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: 2/0 - #6
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: 2/0 - #14
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.82" x 3" x 2.42"
  • Weight: 0 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 2/0 - #14 1 Yes 1323572
Product image for 1323572
  • Catalog #: 1323572
  • Available Cover Part #: CH1323
  • Style: Open
  • Poles: 3
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: 2/0 - #6
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: 2/0 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.54" x 3" x 2.42"
  • Weight: 0.4 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 2/0 - #14 1 Yes 1323972
Product image for 1323972
  • Catalog #: 1323972
  • Available Cover Part #: CH1323
  • Style: Open
  • Poles: 3
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: 2/0 - #6
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: 2/0 - #14
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.54" x 3" x 2.42"
  • Weight: 0 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 #4 - #14 4 Yes 1322970
Product image for 1322970
  • Catalog #: 1322970
  • Available Cover Part #: CH1322
  • Style: Open
  • Poles: 2
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: #4 - #14
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.82" x 3" x 2.42"
  • Weight: 0.52 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 #4 - #14 4 Yes 1323970
Product image for 1323970
  • Catalog #: 1323970
  • Available Cover Part #: CH1323
  • Style: Open
  • Poles: 3
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: #4 - #14
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.54" x 3" x 2.42"
  • Weight: 0.65 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #12 1 #4 - #14 4 Yes 1323570
Product image for 1323570
  • Catalog #: 1323570
  • Available Cover Part #: CH1323
  • Style: Open
  • Poles: 3
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: #4 - #6
  • Line Side CU Wire Range: 2/0 - #12
  • Load Side CU Wire Range: #4 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.54" x 3" x 2.42"
  • Weight: 0.4 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #12 1 #4 - #14 4 Yes 1322570
Product image for 1322570
  • Catalog #: 1322570
  • Available Cover Part #: CH1322
  • Style: Open
  • Poles: 2
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: #4 - #6
  • Line Side CU Wire Range: 2/0 - #12
  • Load Side CU Wire Range: #4 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.82" x 3" x 2.42"
  • Weight: 0.28 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #12 1 #4 - #14 4 Yes 1321570
Product image for 1321570
  • Catalog #: 1321570
  • Available Cover Part #: CH1321
  • Style: Open
  • Poles: 1 - Snap-on
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: #4 - #6
  • Line Side CU Wire Range: 2/0 - #12
  • Load Side CU Wire Range: #4 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1" x 3" x 2.42"
  • Weight: 0.16 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 #4 - #14 4 Yes 1321970
Product image for 1321970
  • Catalog #: 1321970
  • Available Cover Part #: CH1321
  • Style: Open
  • Poles: 1 - Snap-on
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: #4 - #14
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1" x 3" x 2.42"
  • Weight: 0.27 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 #4 - #14 6 -- 1321580
Product image for 1321580
  • Catalog #: 1321580
  • Available Cover Part #: CH1321
  • Style: Open
  • Poles: 1 - Snap-on
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: #6
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: #4 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1" x 3" x 2.42"
  • Weight: 0.17 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 #4 - #14 6 -- 1322580
Product image for 1322580
  • Catalog #: 1322580
  • Available Cover Part #: CH1322
  • Style: Open
  • Poles: 2
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: #6
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: #4 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.82" x 3" x 2.42"
  • Weight: 0.4 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 #4 - #14 6 -- 1323580
Product image for 1323580
  • Catalog #: 1323580
  • Available Cover Part #: CH1323
  • Style: Open
  • Poles: 3
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: #6
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: #4 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.54" x 3" x 2.42"
  • Weight: 0.5 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 #4 - #14 6 Yes 1341580
Product image for 1341580
  • Catalog #: 1341580
  • Available Cover Part #: CH1341
  • Style: Open
  • Poles: 1 - Snap-on
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: #4 - #6
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: #4 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.17" x 5" x 3.92"
  • Weight: -- lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 #4 - #14 6 Yes 1342580
Product image for 1342580
  • Catalog #: 1342580
  • Available Cover Part #: CH1341 (2X)
  • Style: Open
  • Poles: 2
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: #4 - #6
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: #4 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    4.24" x 5" x 3.92"
  • Weight: -- lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 #4 - #14 6 Yes 1343580
Product image for 1343580
  • Catalog #: 1343580
  • Available Cover Part #: CH1343
  • Style: Open
  • Poles: 3
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: #4 - #6
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: #4 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.64" x 5" x 3.92"
  • Weight: 2.73 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 (6) #8 - #14 & (2) #4 - #14 8 -- 1323587
Product image for 1323587
  • Catalog #: 1323587
  • Available Cover Part #: CH1323
  • Style: Open
  • Poles: 3
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: #4 - #6
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: (6) #8 - #14 & (2) #4 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.54" x 3" x 2.42"
  • Weight: 0.5 lbs.
  • Agency Approvals: UL Recognized
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 (6) #8 - #14 & (2) #4 - #14 8 -- 1322587
Product image for 1322587
  • Catalog #: 1322587
  • Available Cover Part #: CH1322
  • Style: Open
  • Poles: 2
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: #4 - #6
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: (6) #8 - #14 & (2) #4 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.82" x 3" x 2.42"
  • Weight: 0 lbs.
  • Agency Approvals: UL Recognized
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 (6) #8 - #14 & (2) #4 - #14 8 -- 1321587
Product image for 1321587
  • Catalog #: 1321587
  • Available Cover Part #: CH1321
  • Style: Open
  • Poles: 1 - Snap-on
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: #4 - #6
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: (6) #8 - #14 & (2) #4 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1" x 3" x 2.42"
  • Weight: 0.2 lbs.
  • Agency Approvals: UL Recognized
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 3/0 - #14 1 Yes 1342572
Product image for 1342572
  • Catalog #: 1342572
  • Available Cover Part #: CH1341 (2X)
  • Style: Open
  • Poles: 2
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #6
  • Load Side AL Wire Range: 3/0 - #6
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: 3/0 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    4.24" x 5" x 3.92"
  • Weight: -- lbs.
  • Agency Approvals: UL Listed, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 3/0 - #14 1 Yes 1341572
Product image for 1341572
  • Catalog #: 1341572
  • Available Cover Part #: CH1341
  • Style: Open
  • Poles: 1 - Snap-on
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #6
  • Load Side AL Wire Range: 3/0 - #6
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: 3/0 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.17" x 5" x 3.92"
  • Weight: -- lbs.
  • Agency Approvals: UL Listed, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 3/0 - #14 1 Yes 1343572
Product image for 1343572
  • Catalog #: 1343572
  • Available Cover Part #: CH1343
  • Style: Open
  • Poles: 3
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #6
  • Load Side AL Wire Range: 3/0 - #6
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: 3/0 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.64" x 5" x 3.92"
  • Weight: 2.73 lbs.
  • Agency Approvals: UL Listed, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 #2 - #14 4 Yes 1343570
Product image for 1343570
  • Catalog #: 1343570
  • Available Cover Part #: CH1343
  • Style: Open
  • Poles: 3
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #8
  • Load Side AL Wire Range: #2 - #8
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: #2 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.64" x 5" x 3.92"
  • Weight: 2.73 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 #2 - #14 4 Yes 1341570
Product image for 1341570
  • Catalog #: 1341570
  • Available Cover Part #: CH1341
  • Style: Open
  • Poles: 1 - Snap-on
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #8
  • Load Side AL Wire Range: #2 - #8
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: #2 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.17" x 5" x 3.92"
  • Weight: -- lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 #2 - #14 4 Yes 1342570
Product image for 1342570
  • Catalog #: 1342570
  • Available Cover Part #: CH1341 (2X)
  • Style: Open
  • Poles: 2
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #8
  • Load Side AL Wire Range: #2 - #8
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: #2 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    4.24" x 5" x 3.92"
  • Weight: -- lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 (2) #2 - #14 & (6) #6 - #14 8 Yes 1343548
Product image for 1343548
  • Catalog #: 1343548
  • Available Cover Part #: CH1343
  • Style: Open
  • Poles: 3
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #6
  • Load Side AL Wire Range: #2 - #6
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: (2) #2 - #14 & (6) #6 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.64" x 5" x 3.92"
  • Weight: 2.73 lbs.
  • Agency Approvals: UL Listed, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 (2) #2 - #14 & (6) #6 - #14 8 Yes 1342548
Product image for 1342548
  • Catalog #: 1342548
  • Available Cover Part #: CH1341 (2X)
  • Style: Open
  • Poles: 2
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #6
  • Load Side AL Wire Range: #2 - #6
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: (2) #2 - #14 & (6) #6 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    4.24" x 5" x 3.92"
  • Weight: -- lbs.
  • Agency Approvals: UL Listed, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 (2) #2 - #14 & (6) #6 - #14 8 Yes 1341548
Product image for 1341548
  • Catalog #: 1341548
  • Available Cover Part #: CH1341
  • Style: Open
  • Poles: 1 - Snap-on
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #6
  • Load Side AL Wire Range: #2 - #6
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: (2) #2 - #14 & (6) #6 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.17" x 5" x 3.92"
  • Weight: -- lbs.
  • Agency Approvals: UL Listed, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 350 - #6 1 Yes 1341582
Product image for 1341582
  • Catalog #: 1341582
  • Available Cover Part #: CH1341
  • Style: Open
  • Poles: 1 - Snap-on
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: 350 - #6
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: 350 - #6
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.17" x 5" x 3.92"
  • Weight: -- lbs.
  • Agency Approvals: UL Listed, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 350 - #6 1 Yes 1342582
Product image for 1342582
  • Catalog #: 1342582
  • Available Cover Part #: CH1341 (2X)
  • Style: Open
  • Poles: 2
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: 350 - #6
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: 350 - #6
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    4.24" x 5" x 3.92"
  • Weight: -- lbs.
  • Agency Approvals: UL Listed, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 350 - #6 1 Yes 1343582
Product image for 1343582
  • Catalog #: 1343582
  • Available Cover Part #: CH1343
  • Style: Open
  • Poles: 3
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: 350 - #6
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: 350 - #6
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.64" x 5" x 3.92"
  • Weight: 2.73 lbs.
  • Agency Approvals: UL Listed, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 2/0 - #14 2 Yes 1343554
Product image for 1343554
  • Catalog #: 1343554
  • Available Cover Part #: CH1343
  • Style: Open
  • Poles: 3
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: 2/0 - #14
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: 2/0 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.64" x 5" x 3.92"
  • Weight: -- lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 2/0 - #14 2 Yes 1342554
Product image for 1342554
  • Catalog #: 1342554
  • Available Cover Part #: CH1341 (2X)
  • Style: Open
  • Poles: 2
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: 2/0 - #14
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: 2/0 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    4.24" x 5" x 3.92"
  • Weight: -- lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 2/0 - #14 2 Yes 1341554
Product image for 1341554
  • Catalog #: 1341554
  • Available Cover Part #: CH1341
  • Style: Open
  • Poles: 1 - Snap-on
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: 2/0 - #14
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: 2/0 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.17" x 5" x 3.92"
  • Weight: -- lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 #8 - #14 24 -- 1332324
Product image for 1332324
  • Catalog #: 1332324
  • Available Cover Part #: CH1332
  • Style: Open
  • Poles: 2
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: #8 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    3.66" x 4" x 3.33"
  • Weight: 0.42 lbs.
  • Agency Approvals: UL Recognized, Canadian UL Recognized, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 #8 - #14 24 -- 1333324
Product image for 1333324
  • Catalog #: 1333324
  • Available Cover Part #: CH1333
  • Style: Open
  • Poles: 3
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: #8 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.36" x 4" x 3.33"
  • Weight: 0.42 lbs.
  • Agency Approvals: UL Recognized, Canadian UL Recognized, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 #8 - #14 24 -- 1331324
Product image for 1331324
  • Catalog #: 1331324
  • Available Cover Part #: CH1331
  • Style: Open
  • Poles: 1
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: #8 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.96" x 4" x 3.33"
  • Weight: 0.53 lbs.
  • Agency Approvals: UL Recognized, Canadian UL Recognized, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
335 400 - #6 1 #2 - #14 6 Yes 1341553
Product image for 1341553
  • Catalog #: 1341553
  • Available Cover Part #: CH1341
  • Style: Open
  • Poles: 1 - Snap-on
  • Amps: 335
  • Volts: 600
  • Line Side AL Wire Range: 400 - #6
  • Load Side AL Wire Range: #2 - #14
  • Line Side CU Wire Range: 400 - #6
  • Load Side CU Wire Range: #2 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.17" x 5" x 3.92"
  • Weight: -- lbs.
  • Agency Approvals: UL Listed, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
