Zero Torque Power Distribution Blocks

General Information

Zero Torque Power Distribution Blocks have push-in terminals for all load distributing terminals. These blocks eliminate the torque process required on traditional mechanical terminals. This simplifies the process to remove specialized equipment, labor and time.

Use Selector Tool

Watch to Learn More

Key Benefits

Amps Catalog Number Poles Line Side Load Side Feeder Circuit Compliant Datasheet Purchase
Openings Wire Range Openings Wire Range
85 ZT3101 3 1 4-#10 6 6-#14 Yes Datasheet Check Distributor Stock
85 ZT2101 2 1 4-#10 6 6-#14 Yes Datasheet Check Distributor Stock
175 ZT3102 3 1 2/0-#6 8 (2) 4-#14
(6) 6-#14
Yes Datasheet Check Distributor Stock
175 ZT3111 3 1 4-#14 8 6-#14 Yes Coming Q124 Coming Q124
175 ZT2111 3 1 4-#14 8 6-#14 Yes Coming Q124 Coming Q124
175 ZT3112 3 1 2/0-#10 8 6-#14 Yes Coming Q124 Coming Q124
