Power Distribution Block Selector Tool

FILTERS

Style

Poles

Amps

Select minimum amps

Volts

Select minimum volts

Line Side Connector Openings/Poles

Line Side Wire Range

Load Side Connector Openings/Poles

Load Side Wire Range

Connector Material

Insulator Material

Agency

Clear Filters

Amps LINE SIDE LOAD SIDE Feeder Circuit Compliant per UL 508 Catalog #
Wire Range
AWG / kcmil		 Connector
Openings / Pole		 Wire Range
AWG / kcmil		 Connector
Openings / Pole
70 Prepared Wire #10 Screw 1 Prepared Wire #10 Screw 1 -- 1411100
No image available for 1411100
  • Catalog #: 1411100
  • Available Cover Part #: CC1411
  • Style: Open w/ Stud(s)
  • Poles: 1
  • Amps: 70
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    .85" x 2.29" x 1.62"
  • Weight: -- lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
70 Prepared Wire #10 Screw 1 Prepared Wire #10 Screw 1 -- 1412100
No image available for 1412100
  • Catalog #: 1412100
  • Available Cover Part #: CC1412
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 70
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.48" x 2.29" x 1.62"
  • Weight: -- lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
70 Prepared Wire #10 Screw 1 Prepared Wire #10 Screw 1 -- 1414100
No image available for 1414100
  • Catalog #: 1414100
  • Available Cover Part #: CC1414
  • Style: Open w/ Stud(s)
  • Poles: 4
  • Amps: 70
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.75" x 2.29" x 1.62"
  • Weight: -- lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
70 Prepared Wire #10 Screw 1 Prepared Wire #10 Screw 1 -- 1413100
No image available for 1413100
  • Catalog #: 1413100
  • Available Cover Part #: CC1413
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 70
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.12" x 2.29" x 1.62"
  • Weight: -- lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 Prepared Wire lug anchored with 10 - 32 screw 1 -- 1413200
Product image for 1413200
  • Catalog #: 1413200
  • Available Cover Part #: CC1413
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.12" x 2.29" x 1.62"
  • Weight: 0 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 Prepared Wire 10 - 32 studs 1 -- 1413203
Product image for 1413203
  • Catalog #: 1413203
  • Available Cover Part #: CC1413
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.12" x 2.29" x 1.62"
  • Weight: 0.21 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 Prepared Wire lug anchored with 10 - 32 screw 1 -- 1414200
Product image for 1414200
  • Catalog #: 1414200
  • Available Cover Part #: CC1414
  • Style: Open w/ Stud(s)
  • Poles: 4
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.75" x 2.29" x 1.62"
  • Weight: 0.28 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 Prepared Wire lug anchored with 10 - 32 screw 1 -- 1414201
Product image for 1414201
  • Catalog #: 1414201
  • Available Cover Part #: CC1414
  • Style: Open w/ Stud(s)
  • Poles: 4
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.75" x 2.29" x 1.62"
  • Weight: 0.25 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 Prepared Wire 10 - 32 studs 1 -- 1414203
Product image for 1414203
  • Catalog #: 1414203
  • Available Cover Part #: CC1414
  • Style: Open w/ Stud(s)
  • Poles: 4
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.75" x 2.29" x 1.62"
  • Weight: 0.13 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 Prepared Wire lug anchored with 10 - 32 screw 1 -- 1412200
Product image for 1412200
  • Catalog #: 1412200
  • Available Cover Part #: CC1412
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.48" x 2.29" x 1.62"
  • Weight: 0.15 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 Prepared Wire 10 - 32 studs 1 -- 1412203
Product image for 1412203
  • Catalog #: 1412203
  • Available Cover Part #: CC1412
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.48" x 2.29" x 1.62"
  • Weight: 0.15 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 Prepared Wire lug anchored with 10 - 32 screw 1 -- 1411200
Product image for 1411200
  • Catalog #: 1411200
  • Available Cover Part #: CC1411
  • Style: Open w/ Stud(s)
  • Poles: 1
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #14
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    0.85" x 2.29" x 1.62"
  • Weight: 0 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
115 #2 - #14 1 Prepared Wire 10 - 32 studs 1 -- 1411203
Product image for 1411203
  • Catalog #: 1411203
  • Available Cover Part #: CC1411
  • Style: Open w/ Stud(s)
  • Poles: 1
  • Amps: 115
  • Volts: 600
  • Line Side AL Wire Range: #2 - #12
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: #2 - #14
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    0.85" x 2.29" x 1.62"
  • Weight: 0 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 Prepared Wire M6 Stud 1 Yes 1321474
Product image for 1321474
  • Catalog #: 1321474
  • Available Cover Part #: CH1321
  • Style: Open w/ Stud(s)
  • Poles: 1 - Snap-on
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1" x 3" x 2.42"
  • Weight: 0.16 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 Prepared Wire 1/4 - 20 stud 1 Yes 1321574
Product image for 1321574
  • Catalog #: 1321574
  • Available Cover Part #: CH1321
  • Style: Open w/ Stud(s)
  • Poles: 1 - Snap-on
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1" x 3" x 2.42"
  • Weight: 0.14 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 Prepared Wire M6 Stud 1 Yes 1322474
Product image for 1322474
  • Catalog #: 1322474
  • Available Cover Part #: CH1322
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.82" x 3" x 2.42"
  • Weight: 0.29 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 Prepared Wire 1/4 - 20 stud 1 Yes 1322574
Product image for 1322574
  • Catalog #: 1322574
  • Available Cover Part #: CH1322
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.82" x 3" x 2.42"
  • Weight: 0.26 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 Prepared Wire M6 Stud 1 Yes 1323474
Product image for 1323474
  • Catalog #: 1323474
  • Available Cover Part #: CH1323
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.54" x 3" x 2.42"
  • Weight: 0.39 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
175 2/0 - #14 1 Prepared Wire 1/4 - 20 stud 1 Yes 1323574
Product image for 1323574
  • Catalog #: 1323574
  • Available Cover Part #: CH1323
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 175
  • Volts: 600
  • Line Side AL Wire Range: 2/0 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 2/0 - #14
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.54" x 3" x 2.42"
  • Weight: 0.39 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 Prepared Wire 1/4 - 20 stud 1 Prepared Wire 1/4 - 20 stud 1 Yes 1321122
Product image for 1321122
  • Catalog #: 1321122
  • Available Cover Part #: CH1321
  • Style: Open w/ Stud(s)
  • Poles: 1 - Snap-on
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1" x 3" x 2.42"
  • Weight: 0.18 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 Prepared Wire M6 Stud 1 Prepared Wire M6 Stud 1 Yes 1321422
Product image for 1321422
  • Catalog #: 1321422
  • Available Cover Part #: CH1321
  • Style: Open w/ Stud(s)
  • Poles: 1 - Snap-on
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1" x 3" x 2.42"
  • Weight: 0.19 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 Prepared Wire 1/4 - 20 stud 1 Prepared Wire 1/4 - 20 stud 1 Yes 1323122
Product image for 1323122
  • Catalog #: 1323122
  • Available Cover Part #: CH1323
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.54" x 3" x 2.42"
  • Weight: 0.49 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 Prepared Wire M6 Stud 1 Prepared Wire M6 Stud 1 Yes 1323422
Product image for 1323422
  • Catalog #: 1323422
  • Available Cover Part #: CH1323
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.54" x 3" x 2.42"
  • Weight: 0.47 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 Prepared Wire 1/4 - 20 stud 1 Prepared Wire 1/4 - 20 stud 1 Yes 1322122
Product image for 1322122
  • Catalog #: 1322122
  • Available Cover Part #: CH1322
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.82" x 3" x 2.42"
  • Weight: 0.33 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 Prepared Wire M6 Stud 1 Prepared Wire M6 Stud 1 Yes 1322422
Product image for 1322422
  • Catalog #: 1322422
  • Available Cover Part #: CH1322
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.82" x 3" x 2.42"
  • Weight: 0.33 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
260 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 1/4 - 20 stud 2 -- 1441122
Product image for 1441122
  • Catalog #: 1441122
  • Available Cover Part #: CC1441
  • Style: Open w/ Stud(s)
  • Poles: 1
  • Amps: 260
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    2.28" x 4.75" x 2.91"
  • Weight: 0.98 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
260 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 1/4 - 20 stud 2 -- 1442122
Product image for 1442122
  • Catalog #: 1442122
  • Available Cover Part #: CC1442
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 260
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    4.16" x 4.75" x 2.91"
  • Weight: 1.16 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
260 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 1/4 - 20 stud 2 -- 1443122
Product image for 1443122
  • Catalog #: 1443122
  • Available Cover Part #: CC1443
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 260
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    6.03" x 4.75" x 2.91"
  • Weight: 2.24 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 Prepared Wire M10 Stud 1 -- 1333558
Product image for 1333558
  • Catalog #: 1333558
  • Available Cover Part #: CH1333
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.36" x 4" x 3.33"
  • Weight: 0 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 Prepared Wire 3/8 - 16 Stud 1 -- 1333559
Product image for 1333559
  • Catalog #: 1333559
  • Available Cover Part #: CH1333
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.36" x 4" x 3.33"
  • Weight: 1.29 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 3/8 - 16 Stud 1 -- 1333563
Product image for 1333563
  • Catalog #: 1333563
  • Available Cover Part #: CH1333
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.36" x 4" x 3.33"
  • Weight: 1.48 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 Prepared Wire M10 Stud 1 Prepared Wire M10 Stud 1 -- 1333564
Product image for 1333564
  • Catalog #: 1333564
  • Available Cover Part #: CH1333
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.36" x 4" x 3.33"
  • Weight: 1.8 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 Prepared Wire M10 Stud 1 -- 1331558
Product image for 1331558
  • Catalog #: 1331558
  • Available Cover Part #: CH1331
  • Style: Open w/ Stud(s)
  • Poles: 1
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.96" x 4" x 3.33"
  • Weight: 0 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 Prepared Wire 3/8 - 16 Stud 1 -- 1331559
Product image for 1331559
  • Catalog #: 1331559
  • Available Cover Part #: CH1331
  • Style: Open w/ Stud(s)
  • Poles: 1
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.96" x 4" x 3.33"
  • Weight: 0 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 3/8 - 16 Stud 1 -- 1331563
Product image for 1331563
  • Catalog #: 1331563
  • Available Cover Part #: CH1331
  • Style: Open w/ Stud(s)
  • Poles: 1
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.96" x 4" x 3.33"
  • Weight: 0 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 Prepared Wire M10 Stud 1 Prepared Wire M10 Stud 1 -- 1331564
Product image for 1331564
  • Catalog #: 1331564
  • Available Cover Part #: CH1331
  • Style: Open w/ Stud(s)
  • Poles: 1
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.96" x 4" x 3.33"
  • Weight: 0.47 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 Prepared Wire M10 Stud 1 -- 1332558
Product image for 1332558
  • Catalog #: 1332558
  • Available Cover Part #: CH1332
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    3.66" x 4" x 3.33"
  • Weight: 0.88 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 Prepared Wire 3/8 - 16 Stud 1 -- 1332559
Product image for 1332559
  • Catalog #: 1332559
  • Available Cover Part #: CH1332
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    3.66" x 4" x 3.33"
  • Weight: 0.81 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 3/8 - 16 Stud 1 -- 1332563
Product image for 1332563
  • Catalog #: 1332563
  • Available Cover Part #: CH1332
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    3.66" x 4" x 3.33"
  • Weight: 0.92 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 Prepared Wire M10 Stud 1 Prepared Wire M10 Stud 1 -- 1332564
Product image for 1332564
  • Catalog #: 1332564
  • Available Cover Part #: CH1332
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    3.66" x 4" x 3.33"
  • Weight: 0.91 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
350 Prepared Wire M10 Stud 1 #10 - #14 24 -- HVPB105
Product image for HVPB105
  • Catalog #: HVPB105
  • Available Cover Part #: CH1331
  • Style: Open w/ Stud(s)
  • Poles: 1 - Snap-on
  • Amps: 350
  • Volts: 1500
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: #10 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.09" x 4.5" x 3.76"
  • Weight: 0.62 lbs.
  • Agency Approvals: UL Recognized, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
360 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 3/8 - 16 Stud 2 Yes 1453573
Product image for 1453573
  • Catalog #: 1453573
  • Available Cover Part #: CC1453
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 360
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    8.54" x 5.5" x 3.13"
  • Weight: 5.44 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
360 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 1/4 - 20 stud 2 Yes 1453583
Product image for 1453583
  • Catalog #: 1453583
  • Available Cover Part #: CC1453
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 360
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    8.54" x 5.5" x 3.13"
  • Weight: 5.44 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
360 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 3/8 - 16 Stud 2 Yes 1451573
Product image for 1451573
  • Catalog #: 1451573
  • Available Cover Part #: CC1451
  • Style: Open w/ Stud(s)
  • Poles: 1
  • Amps: 360
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    3.17" x 5.5" x 3.13"
  • Weight: 0 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
360 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 1/4 - 20 stud 2 Yes 1451583
Product image for 1451583
  • Catalog #: 1451583
  • Available Cover Part #: CC1451
  • Style: Open w/ Stud(s)
  • Poles: 1
  • Amps: 360
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    3.17" x 5.5" x 3.13"
  • Weight: 0 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
360 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 3/8 - 16 Stud 2 Yes 1452573
Product image for 1452573
  • Catalog #: 1452573
  • Available Cover Part #: CC1452
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 360
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.88" x 5.5" x 3.13"
  • Weight: 0 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
360 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 1/4 - 20 stud 2 Yes 1452583
Product image for 1452583
  • Catalog #: 1452583
  • Available Cover Part #: CC1452
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 360
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.88" x 5.5" x 3.13"
  • Weight: 2.62 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
380 500 - #4 1 Prepared Wire 1/4 - 20 stud 2 -- 1443569
Product image for 1443569
  • Catalog #: 1443569
  • Available Cover Part #: CC1443
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 380
  • Volts: 600
  • Line Side AL Wire Range: 500 - #4
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 500 - #4
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    6.03" x 4.75" x 2.91"
  • Weight: 0 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
380 500 - #4 1 Prepared Wire 1/4 - 20 stud 2 -- 1442569
Product image for 1442569
  • Catalog #: 1442569
  • Available Cover Part #: CC1442
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 380
  • Volts: 600
  • Line Side AL Wire Range: 500 - #4
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 500 - #4
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    4.16" x 4.75" x 2.91"
  • Weight: 0 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
380 500 - #4 1 Prepared Wire 1/4 - 20 stud 2 -- 1441569
Product image for 1441569
  • Catalog #: 1441569
  • Available Cover Part #: CC1441
  • Style: Open w/ Stud(s)
  • Poles: 1
  • Amps: 380
  • Volts: 600
  • Line Side AL Wire Range: 400 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 500 - #4
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    2.28" x 4.75" x 2.91"
  • Weight: 0 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
