8 TB Stud Military Terminal Blocks

8tbXXF

Molded material is MAI-60 in accordance with MIL-M-14 (Molded material is GDI30F).

Nuts and connectors are provided when appropriate. They are unplated brass and shipped unassembled.

A-A-59125 superseded MIL-T-55164-C in 1997.

These terminal blocks are compliant to the A-A-59125 standard and are constructed to meet both standards.

Stud - A-A-59125 / MIL-T-55164
Double Row, Front Connection						Spec #	Terminal Type	Voltage		Current	Wire & Lug
Catalog #	# of Term		Dim A	Dim B	Nuts			Max Rated	Dielectric with Test	Max Rated	Screw Size	REMD Max Wire Size	MS17143 Lug #	Max Lug Width	RECMD Torque Lb-In (N-M)
Catalog #	w/stud connectors	w/o stud connectors	Dim A	Dim B	Nuts			Max Rated	Dielectric with Test	Max Rated	Screw Size	REMD Max Wire Size	MS17143 Lug #	Max Lug Width	RECMD Torque Lb-In (N-M)
8 TB 02F	2	4	2.50	2.00	6	/14	Double Stud Double Row	300V RMS	2200V RMS	30 AMP 60Hz	#5	#14 AWG	-11	0.282"	8-10
8 TB 06F	6	12	3.38	2.88	10	/14	Double Stud Double Row	300V RMS	2200V RMS	30 AMP 60Hz	#5	#14 AWG	-11	0.282"	8-10
8 TB 08F	8	16	6.50	6.00	24	/14	Double Stud Double Row	300V RMS	2200V RMS	30 AMP 60Hz	#5	#14 AWG	-11	0.282"	8-10
8 TB 10F	10	20	6.50	6.00	24	/14	Double Stud Double Row	300V RMS	2200V RMS	30 AMP 60Hz	#5	#14 AWG	-11	0.282"	8-10
