Power Blocks

FILTERS

Style

Poles

Amps

Select minimum amps

Volts

Select minimum volts

Line Side Connector Openings/Poles

Line Side Wire Range

Load Side Connector Openings/Poles

Load Side Wire Range

Connector Material

Insulator Material

Agency

Amps LINE SIDE LOAD SIDE Feeder Circuit Compliant per UL 508 Catalog #
Wire Range
AWG / kcmil
Connector
Openings / Pole
Wire Range
AWG / kcmil
Connector
Openings / Pole
200 Prepared Wire M6 Stud 1 Prepared Wire M6 Stud 1 -- 1323422
Product image for 1323422
  • Catalog #: 1323422
  • Available Cover Part #: CH1323
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    2.54" x 3" x 2.42"
  • Weight: 0.47 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 3/0 - #14 1 Yes 1343572
Product image for 1343572
  • Catalog #: 1343572
  • Available Cover Part #: CH1343
  • Style: Open
  • Poles: 3
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #6
  • Load Side AL Wire Range: 3/0 - #6
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: 3/0 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.64" x 5" x 3.92"
  • Weight: 2.73 lbs.
  • Agency Approvals: UL Listed, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 Prepared Wire 1/4 - 20 Stud 1 Prepared Wire 1/4 - 20 stud 1 -- 1422122
Product image for 1422122
  • Catalog #: 1422122
  • Available Cover Part #: CC1422
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    1.94" x 2.88" x 1.78"
  • Weight: 0.47 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 Prepared Wire 1/4 x 20 Screw 1 Prepared Wire 1/4 - 20 Screw 1 -- 1422123
Product image for 1422123
  • Catalog #: 1422123
  • Available Cover Part #: CC1422
  • Style: Open Miscellaneous
  • Poles: 2
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    1.94" x 2.88" x 1.78"
  • Weight: 0.43 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 Prepared Wire 1/4 - 20 Stud 1 Prepared Wire 1/4 - 20 stud 1 -- 1423122
Product image for 1423122
  • Catalog #: 1423122
  • Available Cover Part #: CC1423
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    2.75" x 2.88" x 1.78"
  • Weight: 0.63 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 Prepared Wire 1/4 x 20 Screw 1 Prepared Wire 1/4 - 20 Screw 1 -- 1423123
Product image for 1423123
  • Catalog #: 1423123
  • Available Cover Part #: CC1423
  • Style: Open Miscellaneous
  • Poles: 3
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    2.75" x 2.88" x 1.78"
  • Weight: 0.59 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 Prepared Wire 1/4 - 20 Stud 1 Prepared Wire 1/4 - 20 stud 1 -- 1421122
Product image for 1421122
  • Catalog #: 1421122
  • Available Cover Part #: CC1421
  • Style: Open w/ Stud(s)
  • Poles: 1
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    1.13" x 2.88" x 1.78"
  • Weight: .26 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 Prepared Wire 1/4 x 20 Screw 1 Prepared Wire 1/4 - 20 Screw 1 -- 1421123
Product image for 1421123
  • Catalog #: 1421123
  • Available Cover Part #: CC1421
  • Style: Open Miscellaneous
  • Poles: 1
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    1.13" x 2.88" x 1.78"
  • Weight: 0.26 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 3/0 - #14 1 Yes EPBAD42
Product image for EPBAD42
  • Catalog #: EPBAD42
  • Available Cover Part #: N/A
  • Style: Enclosed ( Modular Snap-Together )
  • Poles: 1 - Snap-on
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #6
  • Load Side AL Wire Range: 3/0 - #6
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: 3/0 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.11" x 3.61" x 2.79"
  • Weight: 0.34 lbs.
  • Agency Approvals: UL Listed, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 3/0 - #14 1 Yes EPBAP42
Product image for EPBAP42
  • Catalog #: EPBAP42
  • Available Cover Part #: N/A
  • Style: Enclosed ( Modular Snap-Together )
  • Poles: 1 - Snap-on
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #6
  • Load Side AL Wire Range: 3/0 - #6
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: 3/0 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.11" x 3.61" x 2.71"
  • Weight: 0.33 lbs.
  • Agency Approvals: UL Listed, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 3/0 - #14 1 Yes EPBCP42
Product image for EPBCP42
  • Catalog #: EPBCP42
  • Available Cover Part #: N/A
  • Style: Enclosed ( Modular Snap-Together )
  • Poles: 1 - Snap-on
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: --
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: 3/0 - #14
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.11" x 3.61" x 2.71"
  • Weight: 0.37 lbs.
  • Agency Approvals: UL Listed, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 2 - #14 4 Yes EPBCP45
Product image for EPBCP45
  • Catalog #: EPBCP45
  • Available Cover Part #: N/A
  • Style: Enclosed ( Modular Snap-Together )
  • Poles: 1 - Snap-on
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: --
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: 2 - #14
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.11" x 3.61" x 2.71"
  • Weight: 0.37 lbs.
  • Agency Approvals: UL Listed, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 #2 - #14 4 Yes EPBCD42
Product image for EPBCD42
  • Catalog #: EPBCD42
  • Available Cover Part #: N/A
  • Style: Enclosed ( Modular Snap-Together )
  • Poles: 1 - Snap-on
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: --
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: #2 - #14
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.11" x 3.61" x 2.79"
  • Weight: 0.37 lbs.
  • Agency Approvals: UL Listed, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 #2 - #14 4 Yes EPBCD45
Product image for EPBCD45
  • Catalog #: EPBCD45
  • Available Cover Part #: N/A
  • Style: Enclosed ( Modular Snap-Together )
  • Poles: 1 - Snap-on
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: --
  • Load Side AL Wire Range: --
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: #2 - #14
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.11" x 3.61" x 2.79"
  • Weight: 0.57 lbs.
  • Agency Approvals: UL Listed, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 2 - #14 4 Yes EPBAP45
Product image for EPBAP45
  • Catalog #: EPBAP45
  • Available Cover Part #: N/A
  • Style: Enclosed ( Modular Snap-Together )
  • Poles: 1 - Snap-on
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #6
  • Load Side AL Wire Range: #2 - #6
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: 2 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.11" x 3.61" x 2.71"
  • Weight: 0.33 lbs.
  • Agency Approvals: UL Listed, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 2 - #14 4 Yes EPBAD45
Product image for EPBAD45
  • Catalog #: EPBAD45
  • Available Cover Part #: N/A
  • Style: Enclosed ( Modular Snap-Together )
  • Poles: 1 - Snap-on
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #6
  • Load Side AL Wire Range: #2 - #6
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: 2 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.11" x 3.61" x 2.79"
  • Weight: 0.33 lbs.
  • Agency Approvals: UL Listed, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 #2 - #14 4 Yes 1343570
Product image for 1343570
  • Catalog #: 1343570
  • Available Cover Part #: CH1343
  • Style: Open
  • Poles: 3
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #8
  • Load Side AL Wire Range: #2 - #8
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: #2 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.64" x 5" x 3.92"
  • Weight: 2.73 lbs.
  • Agency Approvals: UL Listed, Canadian UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 (2) #2 - #14 & (6) #6 - #14 8 Yes 1343548
Product image for 1343548
  • Catalog #: 1343548
  • Available Cover Part #: CH1343
  • Style: Open
  • Poles: 3
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #6
  • Load Side AL Wire Range: #2 - #6
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: (2) #2 - #14 & (6) #6 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.64" x 5" x 3.92"
  • Weight: 2.73 lbs.
  • Agency Approvals: UL Listed, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 (2) #2 - #14 & (6) #6 - #14 8 Yes EPBAD48
Product image for EPBAD48
  • Catalog #: EPBAD48
  • Available Cover Part #: N/A
  • Style: Enclosed ( Modular Snap-Together )
  • Poles: 1 - Snap-on
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #6
  • Load Side AL Wire Range: #2 - #6
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: (2) #2 - #14 & (6) #6 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.11" x 3.61" x 2.79"
  • Weight: 0.33 lbs.
  • Agency Approvals: UL Listed, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
200 3/0 - #14 1 (2) #2 - #14 & (6) #6 - #14 8 Yes EPBAP48
Product image for EPBAP48
  • Catalog #: EPBAP48
  • Available Cover Part #: N/A
  • Style: Enclosed ( Modular Snap-Together )
  • Poles: 1 - Snap-on
  • Amps: 200
  • Volts: 600
  • Line Side AL Wire Range: 3/0 - #6
  • Load Side AL Wire Range: #2 - #6
  • Line Side CU Wire Range: 3/0 - #14
  • Load Side CU Wire Range: (2) #2 - #14 & (6) #6 - #14
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    1.11" x 3.61" x 2.71"
  • Weight: 0.33 lbs.
  • Agency Approvals: UL Listed, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
230 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 1/4 - 20 stud 1 -- 1433561
Product image for 1433561
  • Catalog #: 1433561
  • Available Cover Part #: CC1433
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 230
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    5" x 4" x 2.61"
  • Weight: 1.51 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
230 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 3/8 - 16 Stud 1 -- 1433563
Product image for 1433563
  • Catalog #: 1433563
  • Available Cover Part #: CC1433
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 230
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    5" x 4" x 2.61"
  • Weight: 1.64 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
230 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 1/4 - 20 stud 1 -- 1432561
Product image for 1432561
  • Catalog #: 1432561
  • Available Cover Part #: CC1432
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 230
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    3.47" x 4" x 2.61"
  • Weight: 1.01 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
230 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 3/8 - 16 Stud 1 -- 1432563
Product image for 1432563
  • Catalog #: 1432563
  • Available Cover Part #: CC1432
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 230
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    3.47" x 4" x 2.61"
  • Weight: 1.22 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
230 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 1/4 - 20 stud 1 -- 1431561
Product image for 1431561
  • Catalog #: 1431561
  • Available Cover Part #: CC1431
  • Style: Open w/ Stud(s)
  • Poles: 1
  • Amps: 230
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    1.94" x 4" x 2.61"
  • Weight: 0.67 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
230 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 3/8 - 16 Stud 1 -- 1431563
Product image for 1431563
  • Catalog #: 1431563
  • Available Cover Part #: CC1431
  • Style: Open w/ Stud(s)
  • Poles: 1
  • Amps: 230
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    1.94" x 4" x 2.61"
  • Weight: 0.71 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
230 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 3/8 - 16 Stud 1 -- 1441553
Product image for 1441553
  • Catalog #: 1441553
  • Available Cover Part #: CC1441
  • Style: Open w/ Stud(s)
  • Poles: 1
  • Amps: 230
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    2.28" x 4.75" x 2.91"
  • Weight: 0 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
230 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 3/8 - 16 Stud 1 -- 1442553
Product image for 1442553
  • Catalog #: 1442553
  • Available Cover Part #: CC1442
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 230
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    4.16" x 4.75" x 2.91"
  • Weight: 1.66 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
230 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 3/8 - 16 Stud 1 -- 1443553
Product image for 1443553
  • Catalog #: 1443553
  • Available Cover Part #: CC1443
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 230
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    6.03" x 4.75" x 2.91"
  • Weight: 2.3 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
255 250 - #6 1 250 - #6 1 -- 1431124
Product image for 1431124
  • Catalog #: 1431124
  • Available Cover Part #: CC1431
  • Style: Open
  • Poles: 1
  • Amps: 255
  • Volts: 600
  • Line Side AL Wire Range: 250 - #6
  • Load Side AL Wire Range: 250 - #6
  • Line Side CU Wire Range: 250 - #6
  • Load Side CU Wire Range: 250 - #6
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    1.94" x 4" x 2.61"
  • Weight: 0.78 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
255 250 - #6 1 250 - #6 1 -- 1432124
Product image for 1432124
  • Catalog #: 1432124
  • Available Cover Part #: CC1432
  • Style: Open
  • Poles: 2
  • Amps: 255
  • Volts: 600
  • Line Side AL Wire Range: 250 - #6
  • Load Side AL Wire Range: 250 - #6
  • Line Side CU Wire Range: 250 - #6
  • Load Side CU Wire Range: 250 - #6
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    3.47" x 4" x 2.61"
  • Weight: 1.37 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
255 250 - #6 1 250 - #6 1 -- 1433124
Product image for 1433124
  • Catalog #: 1433124
  • Available Cover Part #: CC1433
  • Style: Open
  • Poles: 3
  • Amps: 255
  • Volts: 600
  • Line Side AL Wire Range: 250 - #6
  • Load Side AL Wire Range: 250 - #6
  • Line Side CU Wire Range: 250 - #6
  • Load Side CU Wire Range: 250 - #6
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    5" x 4" x 2.61"
  • Weight: 1.88 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
260 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 1/4 - 20 stud 2 -- 1443122
Product image for 1443122
  • Catalog #: 1443122
  • Available Cover Part #: CC1443
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 260
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    6.03" x 4.75" x 2.91"
  • Weight: 2.24 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
260 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 1/4 - 20 stud 2 -- 1442122
Product image for 1442122
  • Catalog #: 1442122
  • Available Cover Part #: CC1442
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 260
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    4.16" x 4.75" x 2.91"
  • Weight: 1.16 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
260 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 1/4 - 20 stud 2 -- 1441122
Product image for 1441122
  • Catalog #: 1441122
  • Available Cover Part #: CC1441
  • Style: Open w/ Stud(s)
  • Poles: 1
  • Amps: 260
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    2.28" x 4.75" x 2.91"
  • Weight: 0.98 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 350 - #6 1 -- 1433126
Product image for 1433126
  • Catalog #: 1433126
  • Available Cover Part #: CC1433
  • Style: Open
  • Poles: 3
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: 350 - #6
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: 350 - #6
  • Connector Material: AL
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    5" x 4" x 2.61"
  • Weight: 1.56 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 Prepared Wire 3/8 - 16 Stud 1 -- 1432559
Product image for 1432559
  • Catalog #: 1432559
  • Available Cover Part #: CC1432
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    3.47" x 4" x 2.61"
  • Weight: 1.15 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 Prepared Wire 3/8 - 16 Stud 1 -- 1433559
Product image for 1433559
  • Catalog #: 1433559
  • Available Cover Part #: CC1433
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    5" x 4" x 2.61"
  • Weight: 1.55 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 350 - #6 1 -- 1432126
Product image for 1432126
  • Catalog #: 1432126
  • Available Cover Part #: CC1432
  • Style: Open
  • Poles: 2
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: 350 - #6
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: 350 - #6
  • Connector Material: CU
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    3.47" x 4" x 2.61"
  • Weight: 1.16 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 Prepared Wire 3/8 - 16 Stud 1 -- 1431559
Product image for 1431559
  • Catalog #: 1431559
  • Available Cover Part #: CC1431
  • Style: Open
  • Poles: 1
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    1.94" x 4" x 2.61"
  • Weight: 0.68 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 350 - #6 1 -- 1431126
Product image for 1431126
  • Catalog #: 1431126
  • Available Cover Part #: CC1431
  • Style: Open
  • Poles: 1
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: 350 - #6
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: 350 - #6
  • Connector Material: AL
  • Insulator Material: Phenolic
  • Length x Width x Depth:
    1.94" x 4" x 2.61"
  • Weight: 0.68 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 350 - #6 1 Yes 1343582
Product image for 1343582
  • Catalog #: 1343582
  • Available Cover Part #: CH1343
  • Style: Open
  • Poles: 3
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: 350 - #6
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: 350 - #6
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.64" x 5" x 3.92"
  • Weight: 2.73 lbs.
  • Agency Approvals: UL Listed, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 Prepared Wire M10 Stud 1 -- 1333558
Product image for 1333558
  • Catalog #: 1333558
  • Available Cover Part #: CH1333
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.36" x 4" x 3.33"
  • Weight: 0 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 Prepared Wire 3/8 - 16 Stud 1 -- 1333559
Product image for 1333559
  • Catalog #: 1333559
  • Available Cover Part #: CH1333
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.36" x 4" x 3.33"
  • Weight: 1.29 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 3/8 - 16 Stud 1 -- 1333563
Product image for 1333563
  • Catalog #: 1333563
  • Available Cover Part #: CH1333
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.36" x 4" x 3.33"
  • Weight: 1.48 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 Prepared Wire M10 Stud 1 Prepared Wire M10 Stud 1 -- 1333564
Product image for 1333564
  • Catalog #: 1333564
  • Available Cover Part #: CH1333
  • Style: Open w/ Stud(s)
  • Poles: 3
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    5.36" x 4" x 3.33"
  • Weight: 1.8 lbs.
  • Agency Approvals: UL Recognized, CSA Certified
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 350 - #6 1 -- 1332126
Product image for 1332126
  • Catalog #: 1332126
  • Available Cover Part #: CH1332
  • Style: Open
  • Poles: 2
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: 350 - #6
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: 350 - #6
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    3.66" x 4" x 3.33"
  • Weight: 0 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 Prepared Wire M10 Stud 1 -- 1332558
Product image for 1332558
  • Catalog #: 1332558
  • Available Cover Part #: CH1332
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    3.66" x 4" x 3.33"
  • Weight: 0.88 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 350 - #6 1 Prepared Wire 3/8 - 16 Stud 1 -- 1332559
Product image for 1332559
  • Catalog #: 1332559
  • Available Cover Part #: CH1332
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: 350 - #6
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: 350 - #6
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: AL
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    3.66" x 4" x 3.33"
  • Weight: 0.81 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
310 Prepared Wire 3/8 - 16 Stud 1 Prepared Wire 3/8 - 16 Stud 1 -- 1332563
Product image for 1332563
  • Catalog #: 1332563
  • Available Cover Part #: CH1332
  • Style: Open w/ Stud(s)
  • Poles: 2
  • Amps: 310
  • Volts: 600
  • Line Side AL Wire Range: Prepared Wire
  • Load Side AL Wire Range: Prepared Wire
  • Line Side CU Wire Range: Prepared Wire
  • Load Side CU Wire Range: Prepared Wire
  • Connector Material: CU
  • Insulator Material: Thermoplastic
  • Length x Width x Depth:
    3.66" x 4" x 3.33"
  • Weight: 0.92 lbs.
  • Agency Approvals: UL Recognized, CSA Certified, CE Compliant
  • Downloads:
    Datasheet
    STEP File
    RoHS
  • Country of Origin: USA
  • Check Distributor Stock
